basic function range
DCV: 600mV/6V/60V/600V (0.5%+3)
ACV: 600mV/6V/60V/600V (0.8%+5)
dca: 1-600a (2.0%+30)
AC A: 1-600a (2.0%+30)
resistance: 600ω/6kω/60kω/600kω/6mω/60MΩ (0.8%+3)
capacitance: 60nF/600nF/6UF/60UF/600UF/6000UF (3.5%+20)
frequency: 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/20MHz (0.1%+3)
temperature: (-401000 )℃/(01832 ) ℉ (1.0%+5) special function:
Continuity test: less than 50ω10ω
low battery indicator: approx. Less than 2.6 V> Data hold:√
auto power off: about 15 minutes> TRMS test:√
back light display:√
input impedance: 10mω
sampling rate: 3 times/s
AC frequency response: current 50-60Hz/ voltage 50-400hz
operation method: auto or manual range
Max display: 6000
clamp opens: 28mm
battery: 3V (2*AAA battery)
meter colour: orange and black> meter Weight: about 200G (including battery> meter size: 210×110×45mm
standard accessory: test leads, battery, manual, temperature probe, alligator clip notes
1. All clamp meters can measure current through a single wire, if you put two wires into the clamp jaw, the reading will be zero, only from one wire, you will get exact digits.
2.Measure one wire in one time. If measure more than one wires in one time, The reading will be inaccurate. 3. When measuring current, to get more accurate readings, the ambient temperature MUST be 0 to 40℃.
AC/DC Voltage, AC/DC Current, Frequency, Duty Cycle, Diode, Capacitance and Resistance Measurement
Up to 28mm without interrupting the circuit, safely measures AC current without interrupting the circuit.
1 x Clamp Meter
1 x K-Type Thermocouple
1 x Test Leads (Pair)
1 x Alligator Clip(1 pair)
2 x 1.5V AAA Batteries(Inside the Clamp meter)
1 x User Manual
1 x Cloth Pouch
2. 5% discount on orders over $20.
3. All products are sold 100% authentic.
4. 48 hours delivery, 5-10 working days can be delivered.
5. Free 30-day return and 18-month warranty.
6. Note: If you need to purchase multiple pieces or cooperate, please contact us in advance.
